Alpha CNC Double Drill Unit 6-Sided CNC Drilling Machine For Panel Furniture Production
Description
The Alpha CNC dual drilling unit six sided drilling machine is designed specifically for processing standard panel holes and is very suitable for medium to large custom furniture factories. It is equipped with a dual drilling package structure, which can complete six sided drilling operations with one clamping, improving your machining efficiency. Meanwhile, the dual drilling package with six sided drills can help you reduce manual positioning errors during processing, ensuring efficient and stable operation of the production line, and increasing the quantity of bulk orders for cabinets, wardrobes, and other panels.
Features
- The dual independent drill pack equipped with the six sided drill allows for symmetrical drilling on the board simultaneously, with an efficiency improvement of nearly 30% compared to single drilling unit models.
- No need for manual flipping, single board clamping can complete six sided machining in one go. This process reduces labor costs and manual errors.
- The overall framework of the Alpha CNC dual drill pack six sided drill adopts a rigid casting bed, which ensures stability even during long-term continuous shifts. At the same time, the drilling tolerance can be controlled within 0.02mm.
- Equipped with an air flotation workbench, coupled with a feeding and conveying system, it can prevent scratches on the surface of the panel during the feeding process and reduce the scrap rate of your factory’s processed boards.
- The overall layout of mechanical components is simplified, with fewer vulnerable parts. Low failure rate and maintenance cost, suitable for low-cost investment in small factories.
- Wide panel compatibility, supporting commonly used narrow panels and standard size panels in customized furniture.
Parameters
Work size | 1300x2500mm |
Voltage/frequency | 380V/50HZ/3P |
Control system | NC studio V5/Syntec |
Spindle type | 3.5KW Air Cooling Spindle |
Inverter | Best/Fuling/Delta |
Tool magazine capacity | Customizable |
Driver system | Servo motor |
Reducer | Shimpo |
Worktable | Air floatation table |
Lubrication system | 1.5L Automatic lubrication |
Optional items
- Barcode scanning board reader upgrade package, we can install this equipment to allow the drill bit to directly extract processing data from your production barcode on site
- Matching automatic feeding and discharging conveyor frames to reduce manual sheet movement in continuous batch drilling operations
- Heavy duty centralized dust collection component, thoroughly removes sawdust, keeps the work area and machine interior clean, and can run for a long time
- Extended feed rail assembly, supporting the processing of longer workpieces, with a peak total board length of up to 2800mm
- Customized pneumatic clamping accessories designed specifically for securing ultra-thin panels, capable of stopping movement during normal drilling operations
Frequent asked questions
Q: What’s the main difference between double drill unit and single drill unit six-sided drill?
A: The biggest practical difference lies in the drilling efficiency of symmetrical panel holes. A single drilling machine completes hole groups one after another, wasting a lot of production time. Our dual drill bit units work synchronously and can drill symmetrical holes at the same time. This upgrade is of great significance for factories that produce cabinet and wardrobe side panels on a large scale. It is very suitable for large-scale workshops, while single drill models are more suitable for small-scale production and customers with limited equipment budgets.
Q: Which design software files can this machine read directly?
A: This machine can be used in conjunction with almost all popular furniture design and nesting software on the market. It fully supports common file formats such as XML, DXF, and MPR. You can directly import the completed cutting list for one click processing, or use the barcode scanning function to automatically call the processing program. Our on-site technicians will assist you in debugging all file matching and system connection issues during the installation process to ensure smooth operation.
Q: What size panels can this six-sided drilling machine handle?
A: It is very suitable for most traditional custom furniture panel sizes. The standard processing range includes panel lengths from 250mm to 2800mm, widths from 50mm to 1220mm, and thicknesses from 12mm to 45mm. It firmly grips narrow drawer boards and regular wardrobe panels without sliding. If your workshop frequently produces oversized long panels, we can customize extended guide rails to meet your special processing needs.
Q: Can I add an ATC automatic tool changer to this model later?
A: This special model's structure is specifically tailored and optimized for high-precision and high-efficiency drilling work. It does not reserve installation space for the ATC spindle, so it is not feasible to retrofit the automatic tool changer in the future. If you plan to expand your business to include slotting and special forming processes, we recommend that you choose our upgraded six sided drill model equipped with ATC from the beginning for better long-term availability.
cnc 6 sided drilling machine details
Application
- Target Customer
Medium batch customized cabinet and wardrobe factory, panel furniture workshop, office furniture manufacturer, and decoration furniture mass production factory.
- Core Pain Points We Solve
Production facility
Quality control & testing
FAQ
Q: What’s the main difference between double drill unit and single drill unit six-sided drill?
A: The biggest practical difference lies in the drilling efficiency of symmetrical panel holes. A single drilling machine completes hole groups one after another, wasting a lot of production time. Our dual drill bit units work synchronously and can drill symmetrical holes at the same time. This upgrade is of great significance for factories that produce cabinet and wardrobe side panels on a large scale. It is very suitable for large-scale workshops, while single drill models are more suitable for small-scale production and customers with limited equipment budgets.
Q: Which design software files can this machine read directly?
A: This machine can be used in conjunction with almost all popular furniture design and nesting software on the market. It fully supports common file formats such as XML, DXF, and MPR. You can directly import the completed cutting list for one click processing, or use the barcode scanning function to automatically call the processing program. Our on-site technicians will assist you in debugging all file matching and system connection issues during the installation process to ensure smooth operation.
Q: What size panels can this six-sided drilling machine handle?
A: It is very suitable for most traditional custom furniture panel sizes. The standard processing range includes panel lengths from 250mm to 2800mm, widths from 50mm to 1220mm, and thicknesses from 12mm to 45mm. It firmly grips narrow drawer boards and regular wardrobe panels without sliding. If your workshop frequently produces oversized long panels, we can customize extended guide rails to meet your special processing needs.
Q: Can I add an ATC automatic tool changer to this model later?
A: This special model’s structure is specifically tailored and optimized for high-precision and high-efficiency drilling work. It does not reserve installation space for the ATC spindle, so it is not feasible to retrofit the automatic tool changer in the future. If you plan to expand your business to include slotting and special forming processes, we recommend that you choose our upgraded six sided drill model equipped with ATC from the beginning for better long-term availability.
Review
UK Custom Cabinet Workshop
12 March 2026
Before choosing Alpha CNC dual drilling six sided drill, we compared multiple suppliers. After 8 months of continuous production, the precision of the holes processed by the machine can still be consistent, and our scrap rate of the board has also significantly decreased. And whenever we encounter software connectivity issues, their technical team responds quickly.
